Yamaha MG16 Analog Mixer Features:

  • D-PRE mic preamps deliver clean, transparent, and natural sound
  • 3-band EQ on all mono channels for sound-shaping
  • 1-knob compressors provide straightforward dynamics control
  • Pad switch on mono inputs for managing loud sources
  • Metal chassis for durability
  • Rackmount kit included
Technical Specifications
  • Type:Analog
  • Channels:16
  • Faders:15
  • Inputs - Mic Preamps:8 x XLR/TRS Combo, 2 x XLR
  • Phantom Power:12
  • Inputs - Line:8 x TRS, 4 x RCA
  • Outputs - Main:2 x XLR, 2 x TRS
  • Outputs - Direct:2 x TRS (Monitor)
  • Outputs - Other:4 x TRS
  • Aux Sends:2 x Pre/Post, 2 x Post
  • Send/Return I/O:4 x TRS (Sends)
  • Busses/Groups:4 x Bus
  • Headphones:1 x 1/4"
  • EQ Bands:3-band, Sweepable Mid
  • Rackmountable:Yes
  • Height:5.1"
  • Width:17.5"
  • Depth:19.7"
  • Weight:14.6 lbs.
