Product details

More Information
  • FIR-X tuning delivers excellent sound quality with high resolution and a smooth frequency response
  • D-Contour optimizes the DBR10 for main speaker or floor monitor use
  • Onboard mixer lets you select either a direct output or a mixed output
  • Comprehensive inputs for mixer, musical instrument, or media players
  • Amplifier and power supply design provides powerful output from a compact speaker
  • DSP-controlled protection functionality promotes optimum reliability
Technical Specifications
  • Powered:Yes
  • Power Configuration:Bi-amped
  • LF Driver Size:1 x 10"
  • HF Driver Size:1"
  • LF Driver Power Amp:500W
  • HF Driver Power Amp:200W
  • Total Power:700W
  • Inputs:2 x XLR/TRS Combo, 1 x Stereo
  • Outputs:1 x XLR
  • Frequency Range:55Hz-20kHz (-10dB)
  • Crossover Frequency:2.1kHz
  • Maximum Peak SPL:129dB
  • Horizontal Coverage Angle:90 Degrees
  • Vertical Coverage Angle:60 Degrees
  • Enclosure Material:Plastic
  • Mounting Options:Pole Mount with 1.37' socket, Floor Wedge, 2 x M8 Fly Points
  • Power Source:Standard IEC AC cable
  • Height:19.4"
  • Width:12.1"
  • Depth:11.4"
  • Weight:23.2 lbs.
