Product details

Technical Specifications

Active or Passive - Active


System Type - Column


Configuration - 2-way


System Continuous Power - 70 W


System Programme Power - 140 W


System Peak Power - 280 W


Max SPL @ 1m - 106 dB


Freq Response (+/-3 dB) - 40 Hz - 20 kHz


Freq Range (-10 dB) - 35 Hz - 20 kHz


Bi-amp Mode Switch - No


Bluetooth - Yes


IP Certification - None


Driver Brand - Wharfedale Pro


LF Driver Size - 8"


LF Voice Coil Size - 0.5″


Preset Library - No


Input Connector - XLR / 6.35 Jack / 3.5 Jack / BT / USB / SD


Enclosure Material - Polypropylene


Grille Material and Finish - Steel Black


Finish - Black Polypropylene


Handles - 1


Deployment - Ground


Pole Mount - None


Brackets Included - No


Rigging - No


Nominal Coverage (H x V) - 90° x 50°


Sensitivity 2.83v / 1m - n/a dB


System Rated Impedance - n/a


Transformer (T) - No


Transformer Taps (70 V) - No


Transformer Taps (100 V) - No


Input Connectors (T) - No


Amplifier Design - Class D


Line Output - XLR


Main Power - AC 100 V – 230 V


Included Accessory - IR Remote Control / User Manual / AC Cable


Unpacked Height (mm) - 1862.5


Unpacked Width Front (mm) - 317.8


Unpacked Width Rear (mm) - 317.8


Unpacked Depth (mm) - 399


Weight Nett (kg) - 16


Weight Gross (kg) - 17.5
