Product details

Technical Specifications



Active or Passive- Active
System Type- Floor Monitor
Configuration- 2-way
System Continuous Power- 750 W
System Peak Power -1500 W
Max SPL -@ 1m 131 dB
Freq Response (+/-3 dB) 55 Hz - 20 KHz
Freq Range (-10 dB) 50 Hz - 20 KHz
Bi-amp Mode Switch- No
Bluetooth -No
IP Certification None
Driver Brand -Wharfedale Pro
LF Driver Size -12"
Preset Library- No
Input Connector- XLR 1/4" Combo Jack
Enclosure Material -Birch Plywood
Grille Material and Finish -Steel
Finish- Black Paint
Deployment -Ground, Pole
Pole Mount 35 mm
Rigging Yes
M10 10
Nominal Coverage (H x V) 90° x 60°
Amplifier design Class D
Preset list A) WEDGEB) WEDGE HPFC) COUPLEDD) COUPLED HPFE) FOHF) FOH HPFG) CUSTOMH) CUSTOM
Active loudspeaker Input Impedance Balanced: 10 KΩ
Link Connector Balanced Pin XLR Connector
Input sensitivity +4 dBu
Max input level +18 dBu
Power Supply High Efficiency Switching Mode Power Supply
Included Accessory Quick Start Guide, AC Cable
Unpacked - Height (mm) 658
Unpacked - Width Front (mm) 372
Unpacked - Depth (mm) 400.1
Packed - Height (mm) 738
Packed - Width Front (mm) 470
Packed - Width Rear (mm) 470
Packed - Depth (mm) 445
Weight - Nett (kg) 26.5
