Product details

More Information
  • High quality unit configuration, high strength plywood housing
  • High power
  • Applications: indoor and outdoor sound reinforcement in full range, multifunction halls

Technical Specifications


Maximum SPL: 124 dB continuous, 130 dB peak

Impedance: 8 ohms nominal

Frequency Response: 70Hz–18kHz

Dispersion (-6 dB): 70° × 40°

Drivers:

1 × 15" (385mm) / 3" voice coil LF

1 × 1" (25mm) / 1.7" voice coil HF

Crossover Frequencies: 2.2kHz passive

Input Connectors: 2 × Speakon NL4

Rated Power: 400W RMS, 1600W peak

Sensitivity: 97 dB 1 watt / meter

Dimensions: (W)520mm × (H)345mm × (D)495mm

Net Weight: 26kg / pc (F); 22kg / pc (N)
