Product details

More Information

Compact Design: 3" woofer ideal for
installations with space limitations.

Efficient Output:
Delivers 92dB continuous SPL and 95dB peak SPL.

Wide Coverage:
90° angle dispersion ensures uniform sound distribution.

Durable Construction: ABS baffle and backcan for longevity and safety.

Integrated Backcan: Plenum-rated for ceiling installations.

Press Terminal: Simple and fast wiring via plastic spring clip terminal.

Lightweight: Just 1.15 kg per pair—easy to handle and mount.

No Transformer Taps or Selector: Streamlined for direct 8-ohm connection.


Technical Specifications

Impedance: 8 Ohms

Plenum Usage: Yes, backcan included

Transformer Taps: without transformer

Frequency Range (-10dB): 80Hz–10kHz

Backcan: ABS

Sensitivity: 81dB 1w/1m

Baffle/Rim: ABS baffle

Coverage Angle: 90° Angle

Input Connectors: Press type plastic terminal

Color: White

Tap Selector: without selector

Materials: ABS

Grille Color: White

Dimensions (Diameter & Depth):

4.56" (116mm), Mounting Depth: 2.95" (75mm)

Net Weight: 1.15 kg (one pair)

Shipping Weight: 1.38 kg ea; 28.2 kg (8 pair in master carton)

Ceiling Cutout Size: 3.89" (99mm) diameter

Suspension / Safety-Seismic Attachment Points:

spring clip

Power Rating: 2.5–30W

Maximum SPL (1m):
92dB continuous, 95dB peak

Recommended Protective High Pass:
60 Hz high-pass (24dB/oct) for 8ohm direct

Power Capacity (at low-Z):
30 Watts Continuous Program Power / 15 Watts Continuous Pink Noise

DRIVERS:
3" Polypropylene Cone with Rubber Surround, 0.5" PEI Dome
