Product details

More Information
  • LCR Configuration: Designed for Left/Center/Right channels with precise imaging.
  • Dual Polypropylene Woofers: 5.25” woofers provide balanced low-mid response.
  • Pivoting Tweeter: 1” silk dome tweeter offers directional control for accurate sound placement.
  • Improved Sensitivity: 86dB ensures better efficiency in powered systems.
  • Lightweight & Durable: Made from rugged ABS with sleek black body and white grille.
  • Simple Installation: Dog ear brackets for secure, installer-friendly mounting.
Technical Specifications

Impedance: 8 Ohms
Plenum Usage: without plenum
Transformer Taps: without transformer
Frequency Range (-10dB): 55Hz–20kHz
Backcan: without backcan
Sensitivity: 86dB 1w/1m
Baffle/Rim: without baffle
Coverage Angle: 90° Angle
Input Connectors: Spring Binding Posts
Color: BLACK
Tap Selector: without selector
Materials: ABS
Grille Color: White
Dimensions (H × W × D):
15.6" × 7.5" × 3.3"
Net Weight: 2.5 kg (one speaker)
Shipping Weight: 3.1 kg ea; 13.2 kg (4 PCS in master carton)
Wall Cutout Size:
14.3" × 6.25", Mounting Depth (Assuming .5" Drywall): 3.2"
Suspension / Safety-Seismic Attachment Points:
Installer-friendly Dog Ear Installation Brackets
Power Rating: 50W
Maximum SPL (1m):
103dB continuous, 106dB peak
Recommended Protective High Pass:
40 Hz high-pass (24dB/oct) for 8ohm direct
