Product details

More Information

High Output Performance: Delivers 106dB continuous and 109dB peak SPL.

Broad Frequency Range: 40Hz–20kHz with wide 90° coverage angle.

Premium Drivers: 8" Graphite woofers and 1" pivoting aluminum dome tweeters.

Flexible Installation: Installer-friendly dog ear mounting brackets.

Audio Tuning: ±3dB bass and treble contour switches for optimized sound.

Robust Construction: ABS housing ensures durability.

Direct 8-ohm Operation: No transformer taps required.

Technical Specifications

Impedance: 8 Ohm
Plenum Usage: without plenum
Transformer Taps: without transformer
Frequency Range (-10dB): 40Hz–20kHz
Backcan: without backcan
Sensitivity: 85dB 1w/1m
Baffle/Rim: without baffle
Coverage Angle: 90° Angle
Input Connectors: Plastic spring terminal
Color: White
Tap Selector: ±3db Bass & 0hmsTreble Contour Switches
Materials: ABS
Grille Color: White
Dimensions (H × W × D): 14-7/8" × 10-1/8" × 3-3/4"
Net Weight: 3.0 kg (one speaker)
Shipping Weight: 3.85 kg ea; 39.4 kg (8 PCS in master carton)
Wall Cutout Size: 13-5/8" × 8-3/4"
Suspension / Safety-Seismic Attachment Points: Installer-friendly Dog Ear Installation Brackets
Power Rating: 60W
Maximum SPL (1m): 106dB continuous, 109dB peak
Recommended Protective High Pass: 40 Hz high-pass (24dB/oct) for 8ohm direct
