VIFA PRO Vistofte 08N104

Premium 2-Way Coaxial Driver: Includes a 1” silk dome tweeter and 8” PP woofer.

Wide Frequency Response: 50Hz – 20kHz for detailed audio clarity.

High Sensitivity: Rated at 89dB for efficient sound output.

Installer-Friendly: “Easy Connect” terminal block and dog ear brackets.

ABS Surface Frame & Baffle: Lightweight, durable construction.

Selectable Transformer Taps: Ideal for distributed 100V systems.

Pluggable Tap Selector: Allows fast conversion and configuration.

Discreet Look: Black housing with a white grille for a clean ceiling finish.

Impedance: 8 Ohms

Plenum Usage: Without Plenum

Transformer Taps: 100 V-line – 24W, 12W or 6W integral multi-tap transformer

Frequency Range (-10dB): 50Hz–20kHz

Backcan: Without Backcan

Sensitivity: 89dB

Baffle/Rim: ABS baffle

Coverage Angle: 90° Angle

Input Connectors: “Easy Connect” terminal block simplifies installation

Color: Black

Tap Selector: Pluggable strip conversion switch

Materials: ABS surface frame

Grille Color: White

Dimensions (Diameter & Depth):
11.06" × 3.7"

Net Weight: 1.72 kg (one speaker)

Shipping Weight: 2.23 kg ea; 18.5 kg (8 PCS in master carton)

Ceiling Cutout Size: 9.76"

Suspension / Safety-Seismic Attachment Points:
Installer-friendly Dog Ear Installation Brackets

Power Rating: 2.5–40W

Maximum SPL (1m):
101dB continuous, 104dB peak

Recommended Protective High Pass:
40 Hz high-pass (24dB/oct) for 8ohm direct

Power Capacity (at low-Z):
50 Watts Continuous Program Power / 25 Watts Continuous Pink Noise

DRIVERS:
2-Way Coaxial Open Back, 1" Silk dome Tweeter & 8" PP with rubber surround
