Product details

More Information

Type: 2-Way Coaxial Ceiling Speaker

Design: Open back

Color: Black with White Grille

Tweeter: 1” Silk Dome

Woofer: 6½” Polypropylene with Rubber Surround

Frame Material: ABS Surface Frame

Baffle: ABS Baffle

Mounting: Installer-friendly Dog Ear Brackets

Technical Specifications

Impedance: 8 Ohms
Plenum Usage: Without Plenum
Transformer Taps: 24W, 12W or 6W
Frequency Range (-10dB): 65Hz – 20kHz
Backcan: Without Backcan
Sensitivity: 88dB
Baffle/Rim: ABS baffle
Coverage Angle: 90° Angle
Input Connectors: “Easy Connect” terminal block simplifies installation
Color: Black
Tap Selector: Pluggable strip conversion switch
Materials: ABS surface frame
Grille Color: White
Dimensions (Diameter & Depth): 9.13" × 3.5"
Net Weight: 1.45 kg (one speaker)
Shipping Weight: 1.78 kg ea; 14.8 kg (8 PCS in master carton)
Ceiling Cutout Size: 8.07"
Suspension / Safety-Seismic Attachment Points:
Installer-friendly Dog Ear Installation Brackets
Power Rating: 2.5 – 50W
Maximum SPL (1m):
101dB continuous, 104dB peak
Recommended Protective High Pass:
100 V-line – 24W, 12W or 6W integral multi-tap transformer
Power Capacity (at low-Z):
50 Watts Continuous Program Power / 25 Watts Continuous Pink Noise
DRIVERS:
2-Way Coaxial Open Back, 1" Silk dome Tweeter & 6½" PP with rubber surround
