Product details

More Information
  • 550W RMS output with Low Impedance (4–16Ω) & Constant Voltage (70/100V) support
  • 3 zones with individual volume control (100V) for precise audio distribution
  • 3 Mic inputs & 2 Line/Aux inputs for versatile connectivity
  • USB (MP3, WAV) with display, FM & Bluetooth playback options
  • Compact design – Table–top or Rack–mountable
  • Durable, professional-grade build for 24/7 operation


Technical Specifications
  • Rated power: 550W RMS (Max approx. 750W)
  • Frequency response: 80 Hz – 16 kHz (±3 dB)
  • Power supply: AC 115–230V, 50/60Hz
  • Line input sensitivity: -10 dBV (unbalanced)
  • AUX input sensitivity: -6 dBV (balanced)
  • AMP input sensitivity: 0 dBV (unbalanced)
  • Signal-to-noise ratio: Mic > 65 dB
  • Signal-to-noise ratio: AUX > 80 dB
  • Signal-to-noise ratio: Line > 75 dB
  • THD: <1% (typical)
  • Low impedance output: 4–16Ω
  • Constant voltage output: 70V / 100V
  • BGM module: MP3 player, FM, Bluetooth
  • Dimensions: approx. 480 × 350 × 150 mm
  • Weight: approx. 18–22 kg
