Product details

More Information
  • Rated Output : RMS 120W I MAX 170W
  • Frequency Response : 80Hz - 16kHz ± 3 dB
  • Power Supply : AC: 115-230V 50/60Hz
  • Input I Sensitivity : Line: -1OdBv unbalanced ; AUX: -6dBv balanced ; AMP in: OdBv unbalanced
  • THO :
  • S/N Ratio: MIC > 65dB I AUX > 80dB I Line > 75dB
  • Output (0) : 4 - 160
  • Output (V) : 70V, 100V
  • BGM Module : MP3 player, FM, Bluetooth
  • Dimension (W x D x H) : 420 x 260 x 88 mm (16.5" x 10.2" x 3.5")
  • Weight : 10.2 kg (22.7 lbs)
Technical Specifications
  •  Rated power: 120W RMS (Max 170W)
  • Frequency response: 80 Hz – 16 kHz (±3 dB)
  • Power supply: AC 115–230V, 50/60Hz
  • Line input sensitivity: -10 dBV (unbalanced)
  • AUX input sensitivity: -6 dBV (balanced)
  • AMP input sensitivity: 0 dBV (unbalanced)
  • Signal-to-noise ratio: Mic > 65 dB
  • Signal-to-noise ratio: AUX > 80 dB
  • Signal-to-noise ratio: Line > 75 dB
  • THD: Not specified
  • Low impedance output: 4–16Ω
  • Constant voltage output: 70V / 100V
  • BGM module: MP3 player, FM, Bluetooth
  • Dimensions: 420 × 260 × 88 mm
  • Weight: 10.2 kg
