Product details

More Information
  • Bandpass powered subwoofer for portable PA and installation applications
  • 2200W power featuring Klark Teknik Class-D technology
  • High-excursion 18" low-frequency driver with 4" voice coil and double suspension
  • Bass boost and polarity switch for accurate low-frequency system integration
  • Birch plywood enclosure with hard wearing semi-matte-black paint finish
  • Rugged powder coated perforated steel mesh grille
  • 1.4" pole mount to support satellite speaker
  • Plated steel casters with rubber tires
Technical Specifications
  • Powered:Yes
  • LF Driver Size:18"
  • Total Power:2200W
  • Inputs:2 x XLR
  • Outputs:2 x XLR
  • Frequency Range:40Hz-100Hz (±3dB), 30Hz-150Hz (-10dB)
  • Maximum Peak SPL:134dB
  • Mounting Options:Floor
  • Enclosure Material:Birch Plywood
  • Height:23.2"
  • Width:25.2"
  • Depth:20.9"
  • Weight:105.6 lbs.
  • Manufacturer Part Number:0313-AEX86-US1
