The PA Series is a range of high-power amplifiers built to have outstanding sound quality, excellent power efficiency & guaranteed operational reliability. The amplifiers are using two types of power supplies, the switch mode power supply allows operation on voltages as Low as 130V, at the same time Linear Power Supply gives a punch packed performance!

More Information

•  Professional high-power amplifiers.

•  Input: Balanced XLR and 1/4” Stereo Jack.

•  3 switchable operational modes: Stereo, Mono & Bridge.

•  High quality glass epoxy, double-sided PTH PCB’s & high-grade components ensures reliability in even tough ambient environs.

•  High-current toroidal transformers with high-grade cores for greater transient response & low-noise even at 2 Ohms.

•  41-detent rotary volume knobs.

•  Mute, Signal, Clip and fault LED indicators assists you to monitor performance.

•  Intelligent cooling using low-noise variable speed fans & direct mounted over-designed heat-sinks.

•  Sensitivity (0dB or+4 dB) selection switch allows flexibility in connection of input sources.

• Switchable Low-cut switch for protection & tight-low end performance.

•  Switchable Limiter Switch to protects speakers from damage due to distorted input signals.

•  Rated for 2 Ohms operation.

Technical Specification


2 Ω (True RMS),20Hz-20kHz,1% THD:2 x 800 W

2 Ω (EIA), 1kHz , 1%THD:2 x 1225 W

4 Ω (True RMS),20Hz-20kHz,1% THD:2 x 650 W

4 Ω (EIA), 1kHz , 1%THD:2 x 1012 W

8 Ω (True RMS),20Hz-20kHz,1% THD:2 x 350 W

8 Ω (EIA), 1kHz , 1%THD

2 x 595 W


4 Ω (True RMS),20Hz-20kHz,1% THD_:1600 W

4 Ω (EIA), 1kHz , 1%THD_:2450 W

8 Ω (T rue RMS),20Hz-20kHz,1% THD:1300 W

8 Ω (EIA), 1kHz , 1%THD_:2025 W

Damping factor (8 Ω):> 200 :1

Frequency Response:20Hz – 20kHz (±0.5dB)

Protection Devices:Temperature, DC, RFI Short Circuit, Soft-Start, Over load

Input Connector (Per CH.):XLR, 1/4” TRS Jack

Output Connector (Per CH.):Speakon Connector

Dimensions (WxDxH)mm:482 x 455 x 88 (2U)

Net Weight (Kgs.):18
