Features

  • 26 inputs
  • 16 mono microphone channels.
  • 4 stereo returns
  • 4-bus architecture, with sub-group routable to mix
  • Built-in 24 bit Lexicon digital effects processor
  • 32 FX settings
  • Tap Tempo
  • 3 FX parameter adjust rotaries
  • User FX settings store function
  • Direct outputs for multi-track recording individually switch-able for pre-post-fade operation
  • Inserts on all mono channels
  • Inserts on stereo mix output
  • Classic Soundcraft 3-band EQ with swept mid-band
  • Stereo 18dB/octave 100Hz high-pass filter
  • Dual global +48V phantom power split channels 1-8 and 9-16
  • Channel Mute control
  • 10-segment tri-coloured metering
  • Two sub-group outputs
  • Separate mono sum output
  • Integral universal power supply

Applications:
Live Sound: Bands, Small Venues, Clubs, Conferences, Schools, Houses of Worship
Studio Recording: Digital/Analogue Multi-tracking (8 or 16 track), Small/Home Studios, Pre-/Post-Production.

Technical Specifications

Tech Specs

  • Type:Analog
  • Channels:16
  • Faders:20 x 100mm
  • Inputs – Mic Preamps:16 x XLR
  • Phantom Power:16
  • Inputs – Line:16 x 1/4″ (CH 1-16), 2 x RCA (2 TRK)
  • Outputs – Main:2 x XLR (main out), 1 x 1/4″ (mono), 2 x 1/4″ (monitor out)
  • Outputs – Direct:16 x 1/4″
  • Outputs – Other:2 x 1/4″ (Sub)
  • Aux Sends:2 x Pre, 1 x Pre/Post, 1 x FX
  • Send/Return I/O:3 x 1/4″ (Aux), 6 x 1/4″ (Return)
  • Busses/Groups:2 x Bus (Sub)
  • Channel Inserts:2 x 1/4″ (Mix Inserts), 2 x 1/4″ (Sub Inserts)
  • Headphones:1 x 1/4″
  • EQ Bands:3-band, Sweepable Mid
  • Effects:Yes
  • Rackmountable:Yes
  • Height:5.83″
  • Width:17.46″
  • Depth:17.42″
  • Weight:19 lbs.
