Product details

More Information
  • 12 mono mic/line inputs + 2 stereo inputs
  • Premium GB30 mic preamps for high headroom
  • 3-band EQ with swept mid on mono channels
  • 2-band EQ on stereo channels
  • 2 configurable AUX sends (pre/post)
  • Peak LED monitoring on each channel
  • 60mm smooth faders for precise control
  • Insert points on mono channels and master output
  • RCA playback inputs and record outputs
  • Headphone and monitor outputs
  • Rack-mountable design
Technical Specifications
  • Type: Analog mixer
  • Channels: 14 (12 mono + 2 stereo)
  • Mic inputs: 12 × XLR
  • Phantom power: 48V
  • EQ: 3-band with swept mid (mono), 2-band (stereo)
  • Aux sends: 2 (pre/post switchable)
  • Inserts: Available on all mono channels + master
  • Outputs: XLR main outputs + monitor + RCA rec
  • Metering: 10-segment LED meters
  • Faders: 60 mm high-quality
  • Dimensions: approx. 432 × 363 × 91 mm
  • Weight: approx. 5.8 kg
