Shure SCM810 Automatic Mixer Features:

  • Eight balanced mic-line input channels (Phoenix block connectors)
  • One unbalanced 1/4" aux input level control
  • Eight unbalanced 1/4" direct line level outputs
  • One balanced master line/mic level output (Phoenix block connector)
  • Selectable 48-volt phanton power per channel
  • Level selectable peak output limiter
  • Full rack width (single rack height)
Technical Specifications

Tech Specs

  • Type:Analog
  • Channels:8
  • Inputs - Mic Preamps:8 x Block Connectors (Mic/Line)
  • Phantom Power:8 Channels
  • Inputs - Line:8 x Block Connectors (Mic/Line)
  • Inputs - Other:1 x 1/4" (Link), 2 x 1/4" (Aux)
  • Outputs - Main:1 x Block Connector
  • Outputs - Direct:8 x 1/4"
  • Outputs - Other:1 x 1/4" (Link)
  • Headphones:1 x 1/4"
  • EQ Bands:Low-Cut Filter, High-Frequency Shelving/Channel
  • Rackmountable:Yes
  • Height:1.75"
  • Width:19"
  • Depth:12.5"
  • Weight:9.56 lbs.
