Product details

More Information

Key Features

  • For Discreet Miking
  • For Choirs and Instrumental Ensembles
  • Cardioid Polar Pattern
  • Protected Against RFI
  • Attached 25' Cable
  • Included Snap-Fit Windscreen
Technical Specifications

Specifications:

  • Cartridge Type: Electret Condenser
  • Frequency Response: 70–16000 Hz
  • Polar Pattern: Cardioid
  • Output Impedance: 180 Ω
  • Sensitivity (at 1 kHz , open circuit voltage): –33 dBV/Pa[1] (22 mV)
  • Maximum SPL (1 kHz at 1% THD): 120 dB SPL
  • Signal to Noise Ratio (referenced at 94 dB SPL): 67 dB
  • Dynamic Range: 93 dB
  • Self Noise (equivalent SPL, A-weighted, typical): 27 dB SPL
  • Common Mode Rejection (10 Hz to 100 kHz): >45 dB
  • Preamplifier Output Clipping Level (1% THD): -7 dBV
  • Polarity: Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
  • Power Requirements: 11–52 V DC[4], 2.0 mA
  • Environmental Requirements Operating Temperature Range: -18 to 57 °C (0 to 135 °F)
  • Relative Humidity: 0 to 95%
