Product details

More Information
  • 5000 Watt Peak power - 2500 Watt RMS
  • 137 dB max SPL
  • 30 Hz - 120 Hz frequency response
  • 2 x 18" Woofer
  • DSP controlled Input section with selectable presets
  • Delay control
  • Integrated mechanics for multiple configuration with HDL 20-A
  • Baltic birch tour grade cabinet
Technical Specifications
  • ACOUSTICAL SPECIFICATIONS
  • Frequency Response: 30 Hz ÷ 120 Hz
  • Max SPL @ 1m: 137 dB
  • TRANSDUCERS
  • Woofer: 2 x 18'', 4.0'' v.c
  • INPUT/OUTPUT SECTION
  • Input signal: bal/unbal
  • Input connectors: XLR
  • Output connectors: XLR
  • Input sensitivity: -2 dBu/+4 dBu
  • PROCESSOR SECTION
  • Hi-Pass Frequencies: 100 Hz
  • Low-Pass Frequencies: 80 Hz
  • Protections: Thermal, RMS
  • Limiter: Fast Limiter
  • Controls: Xover, Phase switch, Depp/Punch, Output Delay Settings, Cardioi
  • POWER SECTION
  • Total Power: 5000 W Peak, 2500 W RMS
  • Low frequencies: 5000 W Peak, 2500 W RMS
  • Cooling: Convection
  • Connections: Powercon IN/OUT
  • PHYSICAL SPECIFICATIONS
  • Cabinet/Case Material: Baltic birch plywood
  • Hardware: Mounting points
  • Handles: 4 side
  • Grille: Steel
  • Color: Black
  • SIZE
  • Height: 709 mm / 27.91 inches
  • Width: 1109 mm / 43.66 inches
  • Depth: 700 mm / 27.56 inches
  • Weight: 96.4 kg / 212.53 lbs
  • SHIPPING INFORMATION
  • Package Height: 763 mm / 30.04 inches
  • Package Width: 1156 mm / 45.51 inches
  • Package Depth: 753 mm / 29.65 inches
  • Package Weight: 109 kg / 240.3 lbs
