Product details

More Information
  • Up to 131 dB Sound Pressure Level
  • 2100W Class-D Bi-Amplification
  • 45-20000 Hz linear frequency response
  • 1.75" Compression Driver
  • 15" Woofer
  • FiRPHASE zero degrees phase technology
  • Bass Motion Control woofer excursion management
Technical Specifications

Acoustical Specifications

Frequency Response - 45 Hz – 20,000 Hz

Max SPL @ 1 m - 131 dB

Horizontal Coverage Angle - 100°

Vertical Coverage Angle - 60°

Transducers

Compression Driver - 1 × 1.0", 1.75" v.c

Woofer - 1 × 15", 2.5" v.c

Input / Output Section

Input Signal - Balanced / Unbalanced

Input Connectors - XLR, Jack

Output Connectors - XLR

Input Sensitivity - -2 dBu / +4 dBu

Processor Section

Crossover Frequencies - 1600 Hz

Protections - Thermal, RMS

Limiter - Soft Limiter

Controls - Linear, Boost, Stage, Volume

Power Section

Total Power - 2100 W Peak

High Frequencies - 700 W Peak

Low Frequencies - 1400 W Peak

Cooling - Convection

Connections - VDE

Standard Compliance

Safety Agency - CE Compliant

Physical Specifications

Cabinet / Case Material - Plywood

Hardware - 2 × M10 Top, 1 × M10 each side, 1 × M10 bottom, 1 × M10 rear

Handles - 1 × Each Side

Pole Mount / Cap - 35 mm Insert

Grille - Steel

Color - Black

Size / Weight

Height - 705 mm / 27.76 in

Width - 420 mm / 16.54 in

Depth - 451 mm / 17.76 in

Weight - 24.1 kg / 53.13 lb
