Product details

More Information
  • 2200W Two Way Amplifier
  • 137 dB Max SPL
  • 48 kHz, 32 bit DSP processing
  • 1.4" Titanium Compression Driver, 4.0" voice coil
  • 2 x 10" Neodymium Woofers, 2.5" voice coil
  • Exclusive FiRPHASE technology on-board
  • RDNet Control and Management
  • 680 Hz Crossover Point
Technical Specifications
  • ACOUSTICAL SPECIFICATIONS-
  • Frequency Response: 50 Hz ÷ 20000 Hz
  • Max SPL @ 1m: 137 dB
  • Horizontal coverage angle: 100°
  • Vertical coverage angle: 15°
  • TRANSDUCERS-
  • Compression Driver: 1 x 1.4'' neo, 4.0'' v.c
  • Woofer: 2 x 10'' neo, 2.5'' v.c
  • INPUT/OUTPUT SECTION-
  • Input signal: bal/unbal
  • Input connectors: XLR, RDNet Ethercon
  • Output connectors: XLR, RDNet Ethercon
  • Input sensitivity: +4 dBu
  • PROCESSOR SECTION-
  • Crossover Frequencies: 680 Hz
  • Protections: Thermal, RMS
  • Limiter: Soft Limiter
  • Controls: Preset, RDNet bypass
  • RDNet: Yes
  • POWER SECTION-
  • Total Power: 2200 W Peak, 1100 W RMS
  • High frequencies: 600 W Peak, 300 W RMS
  • Low frequencies: 1600 W Peak, 800 W RMS
  • Cooling: Forced
  • Connections: Powercon
  • IN/OUTPHYSICAL SPECIFICATIONS-
  • Cabinet/Case Material: PP Composite
  • Hardware: Array fittings
  • Handles: 2 Side
  • Grille: Steel
  • Color: Black
  • SIZE-
  • Height: 293 mm / 11.54 inches
  • Width: 705 mm / 27.76 inches
  • Depth: 502 mm / 19.76 inches
  • Weight: 25 kg / 55.12 lbs
