Product details

More Information

Features

  • Rear panel gain controls for tamper resistance; 2-dB detents allow for quick and repeatable settings.
  • XLR and detachable Euro-style input connectors
  • DataPort V2 for use with DPV2-compatible signal processing accessories (XC-3, SF-3, LF-3) and DSP-3/DSP-4 (with external power supply)
  • Independent defeatable clip limiters for reduced distortion
  • Selectable high-pass filters (30 Hz or 70 Hz) protect speakers and prevent speaker transformer saturation with minimal effect on program material
  • Front panel LED indicators include power, signal, and clip
  • Covered barrier strip output connectors for safety agency compliance
  • Automatic on-demand variable-speed fan: quiet normal operation, with maximum cooling when needed
  • Rear-to-front air flow helps keep equipment racks cool
  • Stereo, bridge, or parallel operating modes
  • Comprehensive protection circuitry including DC, infrasonic, thermal overload, and short circuit protection
Technical Specifications

Tech Specs

  • Number of Channels:2
  • Power Class:Class AB
  • Watts/Side @ 8 ohms:185W
  • Watts/Side @ 4 ohms:280W
  • Watts/Side @ 2 ohms:430W
  • Watts Bridged:600W @ 8 ohm, 830W @ 4 ohm
  • 70V/100V Output:1500W
  • Inputs:2 x XLR, 2 x 3-pin Euroblock
  • Outputs:1 x Barrier Strip
  • Data I/O:DataPort V2 (DSP control)
  • Cooling System:Variable Speed Fan
  • Filters:Yes
  • Frequency Response:20Hz-20kHz
  • THD:<0.03%
  • Overload Protection:Full short circuit, open circuit, thermal, ultrasonic, RF
  • Rack Spaces:3U
  • Power Source:Standard IEC AC plug
  • Height:5.25"
  • Depth:15.9"
  • Width:19"
  • Weight:36 lbs.
