The E115 is a trapezoidal, two-way loudspeaker using a 15-inch, 500W, die cast aluminum frame woofer with a 3.5-inch voice coil. It is intended for use when high-power and authoritative low-end are needed from a full-range loudspeaker. A 2.8” compression driver attached to the 75° DMTTM waveguide assures that even distant listeners will be well covered.

Enquire Now

Product details

More Information
  • High output, professional quality sound with E115 – 500 W continuous power
  • E Series Entertainment System – Advanced digital signal processing tunings and options using QSC GXD, PLD amplifiers or TouchMix digital mixers.
  • E Series Entertainment System DSP Tunings are now available for PLD, CXD and GXD processing amplifiers:

             - For PLD/CXD visit Amplifier Navigator Software
             - For GXD visit the GXD Firmware Updater

  • Titanium diaphragm for high fidelity and long life
  • Rugged tour-grade textured paint
  • Foam-lined perforated steel grill
  • Available U-Style Yoke and M10 rigging kit for permanent installation
  • Dual angle pole socket
Technical Specifications
  • Powered:No
  • Power Configuration:2-way
  • LF Driver Size:1 x 15" die-cast aluminum woofer
  • HF Driver Size:2.8" compression driver
  • Impedance:8 ohms
  • Power Rating:500W Continuous
  • Inputs:2 x speakON, 1 x barrier strip
  • Total Power:2000W Peak
  • Frequency Range:55Hz-20khz (-6 dB)
  • Horizontal Coverage Angle:75 Degrees Conical DMT
  • Maximum Peak SPL:130dB SPL @ 1m
  • Enclosure Material:Plywood
  • Mounting Options:Pole Mount with 1.37" socket, Floor Wedge, 6 x M10 Fly Points
  • Height:28.2"
  • Width:16.5"
  • Depth:17.5"
  • Weight:68 lbs.
