Product details

Technical Specifications

Type: Active 2-way monitor speaker (bass-reflex)

Woofer: 6.5” aramid-fiber

Tweeter: 1.5” hard-dome aluminium

Amplifier: Class A/B bi-amp (LF: 100 W, HF: 50 W)

Frequency Response: 40 Hz – 50 kHz

Maximum SPL (peak): 109 dB

Crossover Frequency: 1.6 kHz

Input Sensitivity / Gain: –40 dB to +6 dB

Inputs: 1 × Balanced XLR, 1 × Unbalanced RCA

Impedance: 10 kΩ

EQ Controls (room tuning):

Low EQ (50 Hz): –4 / –2 / 0 / +2 dB

Mid EQ (140 Hz): –4 / –2 / –1 / 0 dB

High EQ (10 kHz): –2 / –1 / 0 / +1 dB

Auto-Standby: Yes

Enclosure: Bass-reflex, rigid die-cast housing

Dimensions (W × H × D): 244 mm × 337 mm × 260 mm

Weight: 12.3 kg

Included Accessories: Power cord, rubber feet, bottom cushions, instructions
