P AUDIO P150- 2228
P AUDIO P150- 2228
The P.Audio P150-2228 is a 15-inch (381mm) diameter transducer designed for ues in professional sound system applications. The P150-2228 is optimized for use in two-way and three-way system designs where a combination of accurate bass response and excellent vocal fundamental response is specified. The Pro Series P150-2228 uses a ferrite-based permanent magnetic system coupled to a rigid die-cast aluminum chassis. The rated bandwidth is 40Hz to 2000Hz. This bandwidth is ideal for two-way system designs where the high frequency response is produced by a high efficiency horn loaded compression driver.
More Information
More Information
Technical Specification
Technical Specification
Nominal diameter | 381 mm/15 in |
Power rating | 1000 W(AES) |
Nominal impedance | 8Ω |
Sensitivity | 96 dB |
Frequency range | 40-2000 Hz |
Chassis type | Cast aluminum |
Magnet type | Ferrite |
Magnet weight | 3.6 kg/127 oz |
Voice coil diameter | 99.3 mm/3.9 in |
Coil material | SV-W |
Former material | Glass fiber |
Cone material | Paper |
Surround material | Cloth |
Suspension | Double |
X-max | 3.9 mm/0.15 in |
Gap depth | 12 mm/0.47 in |
Voice coil winding width | 19.9 mm/0.78 in |
Packing dimension WxDxH (mm) | 415 x 415 x 230 |
Net weight | 13 kg/28.7 lb |
Shipping weight | 14.4 kg/31.7 lb |
