P AUDIO 12 BM 300B

P AUDIO 12 BM 300B

The P.Audio 12BM-300B is a high output wide bandwidth transducer. The 12BM-300B is an upgraded design that features many of P.Audio's new technologies and performance upgrades. The 12 inch (305mm) diameter piston will produce extremely high sound pressure levels at both low and mid band frequencies and is ideal for high level response in both live sound and recorded music venues. The transducer has a rated bandwidth of 45Hz to 3000Hz. The transducer uses high energy ferrite magnetics to achieve a very high acoustic output to weight ratio. The 12BM-300B has been optimized for use in two way or three way sound reinforcement systems.

More Information

  • 3" Voice Coil
  • 1200 Watts Peak Power Handling
  • Ferrite Magnetics
  • Precision Circular Wire Geometry
  • Die Cast Aluminum Chassis

Technical Specification



 Nominal diameter   305 mm/12 in
  Power rating   300 W(AES)
  Nominal impedance   8Ω
  Sensitivity   96 dB
  Frequency range   45-3000 Hz
  Chassis type   Cast aluminum
  Magnet type   Ferrite
  Magnet weight   2.3 kg/81.4 oz
  Voice coil diameter   76.2 mm/3 in
  Coil material   CCA-W
  Former material   Glass fiber
  Cone material   Paper
  Surround material   Cloth
  Suspension   Single
  X-max   3.4 mm/0.13 in
  Gap depth   10 mm/0.39 in
  Voice coil winding width   16.8 mm/0.66 in
  Packing dimension WxDxH (mm)   355 x 355 x 195
  Net weight   7.4 kg/16.3 lb
  Shipping weight   8.2 kg/18.1 lb
