Product details

More Information

Powerful Output: 105dB continuous SPL with 108dB peak for large area coverage.

Larger Driver Size: 8" woofer with 0.5" dome tweeter delivers full-bodied
sound.

Wide Frequency Response: 75Hz to 20kHz for full-range clarity.

Enhanced Sensitivity: 88dB (1W/1m) for efficient performance.

Multiple Tap Settings: 30W / 15W / 7.5W for 70V lines and 8 Ohm compatibility.

Durable Build: ABS backcan and baffle with gold-plated spring connectors.

Plenum Rated: Safe for use in air-handling ceiling spaces.

Secure Mounting: Includes stainless steel crochet hook and dog ear brackets.

Technical Specifications

Impedance: 8 Ohms
Plenum Usage: Yes, backcan included
Transformer Taps: 30W, 15W, 7.5W & 8 Ω
Frequency Range (-10dB): 70Hz–20kHz
Backcan: ABS
Sensitivity: 89dB 1W/1m
Baffle/Rim: ABS baffle
Coverage Angle: 90° Angle
Input Connectors: Gold-plated spring connector
Color: White
Tap Selector: Rotary switch accessible from side of backcan
Materials: ABS surface frame, ABS backcan
Grille Color: White
Dimensions (Diameter & Depth): 11" × 7"
Net Weight: 2.25 kg (one speaker)
Shipping Weight: 3.15 kg ea; 11.8 kg (6 PCS in master carton)
Ceiling Cutout Size: 9.31"
Suspension / Safety-Seismic Attachment Points:
Installer-friendly Dog Ear Installation Brackets, Stainless steel crochet hook
Power Rating: 2.5–60W
Maximum SPL (1m):
105dB continuous, 108dB peak
Recommended Protective High Pass:
60 Hz high-pass (24dB/oct) for 8ohm direct
Power Capacity (at low-Z):
60 Watts Continuous Program Power / 30 Watts Continuous Pink Noise
DRIVERS:
Woofer: 8" Polypropylene Cone with Rubber Surround,
Tweeter: 0.5" PEI Dome
