KRYSTALS SLIM-Digital-24 AWG Stage Microphone Cable

KRYSTALS SLIM-Digital-24 AWG Stage Microphone Cable

24 AWG (25/0.10mm) x 2 core ATC copper conductor, PE insulated, core twisted in a circular form, polyester mylar taped, aluminium foil + spiral shielded (97%) with ATC copper, outer Jacketed with Matt finish High Flex Special PVC.

More Information

Krystals 24 AWG Pro Analog Features:

  • Pro Analog Microphone Cable is our Premium range of Microphone Cable for Stage and Touring use.
  • A Reasonable Cross-Sectional Area of Annealed Bare Copper conductor (19 wires of 0.12mm) and dense Braid Shielding with Bare Copper Wires (128 wires of 0.09mm) gives a complete Shield achieving coverage of around 90%.
  • High volume synthetic fibre acts as a filler & holds the 2 conductors giving an excellent performance of the cable even in extreme usage.

Technical Specification


No. of Conductors 2
Conductor ( No. / size of wire) 25/0.10 mm
Cross-Sectional Area 0.22 (24 AWG)
Insulation Material HDPE
Insulation OD 1.10 mm
Insulation Colours Red / Yellow
Shield Conductor ATC Copper – (0.10mm ) 65 wires (approx)
Shield Type Serve Shield + Aluminum Foil + Mylar Tape
Jacket Material High Flex Matt Finish PVC
Jacket OD 4.00 mm + – 0.10mm
Packaging 100 meter Coil
Gross Weight of Coil 2.250 Kgs
Master Packing 8 Coil in Carton
Master packing weight 18.5 kgs

Electrical and Mechanical Characteristics

DC resistance @20 °C – Conductor 88.9 Ω / Km
DC Resistance @ 20 °C -Sheild 35 /Ω Km
Capacitance – Cond / cond 23 pF/Feet
Capacitance – Cond /Shield 52 pF/Feet
Inductance b/w conductors @1kHz 20⁰C 0.8 μH/m
Electrostatic Noise 100mV Max
Electromagnetic Noise 0.15mV Max
Microphonics @ 50KΩ Load 30 mV Max
Impedance 110 Ω
Voltage Breakdown Must withstand DC 30V for 15 seconds
Operating Voltage 300 V
Operating Temperature -20⁰ C to +70⁰ C
Dielectric Constant 1k hz 2.3
Dissipation Factor 0.0002
Flex Life 15,500 cycles
Tensile Strength 659 N
