Building on KLARK TEKNIK’s storied legacy of highest-quality direct injection devices, the DI 20P PRO DI 2 offers the same high headroom, dynamic response and sonic clarity you have come to expect. DI 20P is ideal for interfacing stereo keyboards, samplers and other electronic musical instruments to mixing consoles, and faithfully reproduces the character of electric and acoustic instruments, allowing far more of the detail of musical performances to be captured. A passive device, the DI 20P does not require any form of external power to complete its mission. Equipped with a custom-built MIDAS transformer and switchable input Pad, DI 20P easily accommodates instruments, line, and even loudspeaker level signals – making it the perfect choice for professional audio and multimedia applications.

More Information

  • Passive stereo DI Box for general purpose applications
  • Custom-built Midas transformer for highest signal integrity
  • High headroom design offers superior sound quality
  • Passive design does not require any power supply
  • Stereo inputs on 1/4” TS connectors
  • Through connectors on 1/4” TS connectors
  • Switchable input attenuation for guitar, line and speaker levels
  • High quality Neutrik* XLR connectors

Technical Specification

Passive Stereo DI Box
  • Midas transformer
  • 2x 6.3 mm jack inputs
  • 2x -15 dB pad switch
  • Ground lift
  • Neutrik XLR outputs
  • Sturdy, compact aluminium housing with protective, hard rubber corners
  • Frequency range (±1 dB): 20 Hz - 30 kHz
  • Input impedance: 500 kOhm (10 kOhm/PAD)
  • Output impedance: 150 Ohm (at 1 kHz)
  • Signal-to-noise ratio: 108 dBu
  • Dimensions (W x H x D): 118 x 64 x 112 mm
  • Weight: 0.54 kg
