JTS CX-508

JTS CX-508

The JTS CX-508 Miniature clip on condenser microphone is designed for the miking of brass and woodwind instruments. Its flat response with a slight presence peak in the upper frequencies ensures natural and bright reproduction without coloration.

More Information

  • The lightweight miniature profile provides minimal physical size interference for the performer.
  • Spring type clamp with elastic grip and adjustable gooseneck for secure mounting on the horn without scratching or marring delicate instrument finishes.
  • Clip on design allows optimal placement position thereby eliminating the use of mic stands, reducing stage clutter and set up time.
  • Outstanding for saxophone, brass, woodwind instruments.
  • Extended frequency response and wide dynamic range for pure and natural sound without coloration.
  • Excellent shock-mount design for superior isolation from shock and vibrations.
  • Flexible gooseneck together with adjustable axis allows accurate positioning.
  • Newly added spider suspension isolates unwanted mechanical vibration effectively.

Technical Specification


Type Electret Condenser
Frequency Response 50~18,000 Hz
Polar Pattern Cardioid
Sensitivity(at 1,000Hz)    -64dB*(0.63mV)*
Impedance 220Ω
Max. SPL for 1% T.H.D. 130 dB
Output Connector 3P XLR(M)
Phantom Power Requirements 9-52 VDC
Standard Accessories Windscreen
