Product details

More Information
  • Dual 915H 15” ferrite magnet woofers
  • JBL 2408H-1 1.5” poly-annular diaphragm compression driver
  • Updated JBL image control waveguides improve dispersion
  • FEA flared port design reduces air noise and distortion
  • Low-noise, low-distortion gain staging design
  • Lightweight, efficient Class D amplification
  • Power: 2,000 watts peak/1,000 watts RMS
  • Frequency response: 43 Hz - 20 kHz @4pi (-10 dB); 54 Hz - 17 kHz @4pi (-3 dB)
  • Dispersion: 90° x 50°
  • Max SPL: 137.7 dB
  • Crossover frequency: 1,700 Hz
  • Color LCD screen provides access to comprehensive DSP suite
  • DriveRack Technology includes Automatic Feedback Suppression, system limiter and 180ms of speaker delay in 100-microsecond intervals for precise time-aligned systems
  • Optimized presets for pairing full-range speakers with subwoofers
  • JBL Pro Connect app allows full system control of up to 10 JBL Pro Connect app-enabled speakers and systems
  • 18 mm birch cabinet with optimized bracing delivers smooth, accurate low-frequency response
  • I/Os:2 XLR balanced Combo jacks1 3.5mm aux2 XLR-M loop-through1 XLR-M Mix out
  • Two integrated side handles
  • Suspension/mounting: single 36mm pole socket, eight M10 suspension points
  • Quiet fanless operation
  • Ultra-low system latency: <1ms

Technical Specifications

  • Frequency Range (-10 dB): 43 Hz – 20 kHz (4π)
  • Frequency Range (-3 dB): 54 Hz – 17 kHz (4π)
  • Coverage Pattern: 90° × 50°
  • Transducer Impedance: Woofer: 8 Ω, Tweeter: 8 Ω
  • Maximum SPL: 137.7 dB
  • Power Rating: 2000 W Peak
  • Cooling System: Natural Convection (No Fan)
  • Crossover Frequency: 1700 Hz
  • Inputs: 2 × Combo Inputs, 1 × 3.5 mm Stereo Jack
  • Outputs: 2 × XLR Through Outputs, 1 × Mix Output
  • Suspension / Mounting: 8 × M10 Suspension Points, 1 × 36 mm Pole Mount
  • Dimensions (H × W × D): 1058.5 × 446 × 434 mm (41.7 × 17.6 × 17.1 in)
  • Net Weight: 37.3 kg (82.2 lb)
