Product details

More Information
  • Class-AB topology for low distortion and warm dynamics
  • Robust linear power supply with toroidal transformer
  • Extensive protection: thermal, overload, short circuit, clip limiter
Technical Specifications
  • Code: 39694
  • Both Channels Driven @ 8 Ohm (1% THD Continuous/Impulsive): 230W / 250W
  • Both Channels Driven @ 4 Ohm (1% THD Continuous/Impulsive): 350W / 400W
  • Bridge @ 8 Ohm (1% THD): 700W / 800W
  • Input Impedance: 20 kOhm Balanced
  • Signal to Noise Ratio (S/N): >100dB
  • Total Harmonic Distortion (1kHz / 4 Ohm): <0.03%
  • Frequency Response: 20Hz – 40kHz (-6dB)
  • Damping Factor: >400
  • Class: AB
  • Maximum Power Consumption: 1000VA
  • Power Supply Voltage: 220–230 Vac, 50/60Hz
  • Protections: Short Circuit / Thermal
  • Connectors: IN: XLR/Jack - OUT: Speakon/Binding Post
  • Net Dimensions (WxHxD): 482 x 88 x 290 mm / 19" x 3.5" x 11.4"
