Product details

Technical Specifications

Frequency response (-3 dB) (Hz)156 Hz – 17,000 HzFrequency range (-10 dB) (Hz)145 Hz – 20,000 HzMaximum sound pressure level at a distance of 1 m (dB)2, 3126 dBCoverage angle HxV (°)90° x 60°

Amplifier rating (W)1000 WPower consumption (V, Hz)4100 - 240 V~, 50 - 60 Hz, 1.0 - 0.5 ALF transducer size (in)15 inLF transducer typeWECA2154H wooferLF transducer magnet materialFerriteHF transducer size (in)1 inHF transducer typeDENA2504H compression driverHF transducer diaphragm materialTitanium-coated PEIHF transducer magnet materialNeodymiumCrossover frequency (kHz)1.9 kHzConnector type(2) XLR Combo mic/line input(1) XLR mix outputEnclosureCompositeGrille materialPowder coated steelColorBlackDimensions (H x W x D) (mm)725 mm x 426 mm x 402 mmDimensions (H x W x D) (in)28.54 in x 16.77 in x 15.83 inShipping dimensions (H x W x D) (mm)762 mm x 485 mm x 455 mmShipping dimensions (H x W x D) (in)30.00 in x 19.10 in x 17.91 inWeight (kg)14.6 kgWeight (lb)32.2 lbShipping weight (kg)19.5 kgShipping weight (lb)43.0 lb
