Features

  • Dual 31-band, 1/3-octave Constant Q frequency bands
  • Switchable boost/cut ranges of ±6 or ±12 dB
  • Front panel bypass switch
  • ±12 dB input gain range
  • 4-segment LED ladders for monitoring output levels
  • XLR and TRS Inpts and Outputs
  • Frequency Response of <10Hz to >50kHz
  • Dynamic range of greater than 108dB
Technical Specifications
  • Input Connectors - 1/4" TRS, female XLR (pin 2 hot)
  • Input Type - Electronically balanced/unbalanced, RF filtered
  • Input Impedance - Balanced 40k ohm, unbalanced 20k ohm
  • Max Input - >+21dBu balanced or unbalanced
  • CMRR - >40dB, typically >55dB at 1kHz
  • Output Connectors - 1/4" TRS, male XLR (pin 2 hot)
  • Output Type - Impedance-balanced/unbalanced, RF filtered
  • Output Impedance - Balanced 100 ohm, unbalanced 50 ohm
  • Max Output - >+21dBu balanced/unbalanced into 2k ohm or greater; >+18dBm balanced/unbalanced (into 600 ohm)
  • Bandwidth - 20Hz to 20kHz, +0.5/-1dB
  • Frequency Response - <10Hz to >50kHz, +0.5/-3dB
  • Dynamic Range - Typically >112dB
  • Signal to Noise Ratio - Typically >95dB
  • THD+Noise - <0.003%
  • Interchannel Crosstalk - <-90dB, 20Hz to 20kHz
  • Bypass Switch - Bypasses the graphic equalizer section in the signal path
  • Low cut Switch - Activates the 50Hz 12dB/octave high-pass filter
  • Range Switch - Selects either +/- 6dB or +/-12dB slider boost/cut range
