Product details

More Information

- Peakx Plus Limiters provide the ultimate in system performance and protection by allowing full control over threshold, attack, and release

- Enhanced Subharmonic Synth section provides user control over frequency, gain and filter type for system-specific tuning

- 3 User-defined fan mode controls – normal, early and fullspeed – for matching fan performance to a specific application

- New system monitoring provides software visibility of AC line voltage and power supply temperature

- Integrated cast-aluminum handles for easy handling and enhanced durability

- Locking power cord clip provides a secure connection between the amplifier and power cord

- Updated HiQnet System Architect™ control software

- Increased number of presets to a total of 50; 49 of which are user definable

Technical Specifications

Channels:

2

Sensitivity:

1.4V

Rated Power Output (per channel):

1000W 2Ω, 800W 4Ω, 475W 8Ω

Signal to Noise Ratio (below rated 1 kHz power at 8 ohms):

100 dB (A-weighted)

THD:

< 0.5%

Frequency Response (at 1W, 20 Hz - 20 kHz):

+ 0 dB, -1 dB

Crosstalk (below rated power):

>70 dB

Dimensions:

3.5" x 19" x 12.25"

Weight:

18.5 lbs (8.4 kg)

IEC Power Connector:

15A
