CROWN NCDI 2X300
CROWN NCDI 2X300

CROWN NCDI 2X300

The CDi DriveCore Series is an evolution in amplification, providing an impressive mix of high-performance; rich feature set, and competitive cost.  Using technology derived from our flagship Installed Sound amplifier (Crown DriveCore Install series), the CDi DriveCore 2|300 offers streamlined functionality to work in almost any small/medium sized installation such as restaurants, retail stores, and more.  Designed for ease-of-use in a variety of applications, the 2|300 is a 2-channel amp that includes network control/monitoring, high-level DSP, front-panel interface, and support for driving up to 100Vrms speaker loads without requiring a transformer.  The entire CDi DriveCore line comes pre-loaded with JBL speaker tunings to help make installations quicker and easier.

Enquire Now

Product details

More Information
  • DriveCore Technology
  • Remarkable Performance & Reliability
  • Supports HiQnet Audio Architect Software
  • Monitor & Control over Standard TCP/IP
  • Color LCD Panel for Control & Monitoring
  • Advanced DSP on Inputs & Outputs
  • Works with 70V & 100V Speakers
  • Universal Power Supply
  • 2 Terminal Block Included
  • Included Power Cord
Technical Specifications

Amplifier Channels & Power

Number of Amplifier Channels - 2

Load Impedance / Voltage Support - 4 / 2 / 8 / 16 Ω; 100 / 70 / 200 / 140 V

Power Rating per Channel - 2 × 300 W at 8/4 Ω

Power Rating per Channel (High-Voltage) - 2 × 300 W at 100/70 V

Channel Bridging & Power Sharing - 1 × 300 W Bridged at 4 Ω

Channel Bridging - 1 × 600 W Bridged at 8/16 Ω

Channel Bridging (High-Voltage) - 1 × 600 W Bridged at 140/200 V

Performance

Protections - DC Fault, Low Impedance, Open Circuit, Overcurrent, Overvoltage, Ultrasonic, Undervoltage

Frequency Response - 20 Hz to 20 kHz ±0.5 dB (8 Ω)

Damping Factor - >1000

SNR / Noise - >104 dB

THD - ≤0.35% (at Rated Power)

IMD - ≤0.35%

Crosstalk - >80 dB (Below Rated Power)

Signal Processing

DSP - Yes (32-bit Floating Point DSP at 96 kHz)

Audio Delay - Adjustable up to 1000 ms

EQ & Filters - 8-Band Parametric EQ, High-Pass Filter, Crossover, Low-Pass Filter (Software Controlled)

Dynamics - Limiter

Connectivity

Analog Audio I/O - 1 × Block 6-Pin Balanced Line Input

Speaker Output - 1 × Barrier Strip

Digital Audio I/O - No

Network I/O - 1 × RJ45 Ethernet, 2 × RJ45 BLU LINK

USB - No

Phantom Power - No

Wireless - No

Power

Input Power - 100 to 240 VAC, 60/50 Hz

AC Power Connector - 1 × IEC 15 A / NEMA 5-15

Current Consumption (1/8 Power) - 0.7 to 1.4 A

Current Consumption (1/3 Power) - 1.1 to 2.8 A

Power Consumption (1/8 Power) - 80 to 119 W

Power Consumption (1/3 Power) - 99 to 381 W

Physical

Display - Backlit LCD

Rackmount Size - 2U

Cooling - Variable-Speed Fan

Dimensions - 19 × 12.25 × 3.5 in / 48.26 × 31.12 × 8.89 cm

Weight - 14.5 lb / 6.58 kg
