Product details

More Information
  • Packs high-performance power amplification into a space-saving, 2U rackmount unit
  • Tackles low-impedance applications with aplomb
  • Direct-drive constant voltage accommodates 70V/100V speakers — no step-up transformer required
  • Drives 1–2 speakers in lo-Z mode, or multiple speakers in hi-Z mode
  • Channels are bridgeable — even in 100V mode
  • Integrates effortlessly into a remote control system
  • Highly efficient internal cooling fans provides ample airflow to heat-generating parts
  • Advanced power supply delivers the utmost in efficiency in a whole host of applications
Technical Specifications
  • Number of Channels:4
  • Power Class:Class D
  • Watts/Side @ 8 ohms:300W
  • Watts/Side @ 4 ohms:300W
  • Watts/Side @ 2 ohms:150W
  • 70V/100V Output:300W
  • Inputs:4 x 3-pin Euroblock
  • Outputs:4 x Binding Post
  • Cooling System:Variable Speed Fan
  • DSP:No
  • Filters:No
  • Frequency Response:20Hz-20kHz (±0.25dB)
  • THD:0.35%
  • Rack Spaces:2U
  • Power Source:Standard IEC AC cable
  • Height:3.5"
  • Depth:14.25"
  • Width:19"
  • Weight:20.1 lbs.
