Product details

More Information
  • 8000 Watt power, 4 x onboard amplifiers
  • 143 dB max SPL
  • RDNet networked management and monitoring
  • 48 kHz, 32 bit DSP processing
  • 2 x 12” neodymium woofers
  • 4 x 6" neodymium woofer midrange
  • 2 x 3” titanium dome neodymium compression drivers
  • Remarkably compact and lightweight
Technical Specifications
  • ACOUSTICAL SPECIFICATIONS-
  • Frequency Response: 40 Hz ÷ 20000 Hz
  • Max SPL @ 1m: 143 dB
  • Horizontal coverage angle: 90°
  • Vertical coverage angle: 10°
  • TRANSDUCERS-
  • Compression Driver: 2 x 1.4'' neo, 3.0'' v.c
  • Midrange: 4 x 6.0'' neo, 2.0'' v.c
  • Woofer: 2 x 12'' neo, 3.0'' v.c
  • INPUT/OUTPUT SECTION-
  • Input signal: bal/unbal
  • Input connectors: XLR, RDNet Ethercon
  • Output connectors: XLR, RDNet Ethercon
  • Input sensitivity: +4 dBu
  • PROCESSOR SECTION-
  • Crossover Frequencies: 200 Hz - 800 Hz
  • Protections: Thermal, RMS
  • Limiter: Soft Limiter
  • Controls: Cluster size, HF correction, RDNET
  • RDNet: Yes
  • POWER SECTION-
  • Total Power: 8000 W Peak, 4000 W RMS
  • High frequencies: 2000 W Peak, 1000 W RMS
  • Mid frequencies: 2000 W Peak, 1000 W RMS
  • Low frequencies: 4000 W Peak, 2000 W RMS
  • Cooling: Convection
  • Connections: Powercon IN/OUT
  • PHYSICAL SPECIFICATIONS-
  • Cabinet/Case Material: Baltic birch plywood
  • Hardware: Integrated Mechanics
  • Handles: 2 side, 2 rear
  • Grille: Steel
  • Color: Black
  • SIZE-
  • Height: 366 mm / 14.41 inches
  • Width: 1171 mm / 46.1 inches
  • Depth: 502 mm / 19.76 inches
  • Weight: 58.4 kg / 128.75 lbs
