BOSCH CCSE - CU 700

BOSCH CCSE - CU 700

The Bosch CCSE-CU CCS700 Conference Control Unit is the central controller for the CCS700 discussion system, supporting up to 50 chairman and delegate units. With an integrated amplifier, intuitive controls, audio routing, and priority management, it delivers reliable and clear communication for conferences, meetings, and council sessions.

Enquire Now

Product details

More Information
  • Central controller for up to 50 devices
  • Integrated 2 × 10W amplifier
  • Priority control for chairman units
  • Automatic microphone & speaker management
  • Two auxiliary audio inputs
  • Recording output & monitoring capability
  • Plug-and-play installation with auto-recognition
  • Robust and reliable Bosch design
Technical Specifications

Electrical

Mains Voltage - 230 VAC, 50 Hz (±10%)

DC Voltage Supply to Contribution Units - 24 V ± 1 V DC

THD at Rated Output - <1%

SNR - >-50 dB at rated output (unweighted filter)

Inputs

Mic Input Sensitivity - 1 mV (+1/-3 dB)

Aux Input Sensitivity - 100 mV (+1/-3 dB)

Frequency Response - 200 Hz to 12 kHz

Input Impedance - 4.7 kΩ

Equaliser

Center Frequencies of Filters - 250 Hz, 2 kHz, 8 kHz

Filter Bandwidth - 1 octave

Boost/Cut at Center Frequencies - +6 dB to -6 dB

Equaliser Transfer Gain - ±1 dB

PA Output

Rated Output Impedance - 100 Ω

SNR - >-50 dB at rated output (unweighted filter)

REC Out

Rated Output Impedance - 1 kΩ

SNR - >-50 dB at rated output (unweighted filter)

Dimensions (H × W × D)

Dimensions - 88 mm × 361 mm × 252 mm

Weight

Weight - 5.5 kg

Color

Color - Charcoal (RAL 10736) and Grey (rear cover)

Environmental

Operating Temperature - -5°C to 45°C

Storage Temperature - -40°C to +70°C
