Product details

More Information

Parameters

Fs

39 Hz

Qes

0.3

Qts

0.29

Sd

855 cm² (132.5 in²)

Xmax

8 mm

Mms

154 g

Le

2 mH

Re

5.2 Ω

Qms

6.5

Vas

110 dm³ (3.8 ft³)

η0

2.1 %

Xvar

6.5 mm

Bl

25.8 Tm

EBP

130 Hz

Design

Surround Shape

Double Roll

Magnet Material

Ferrite

Pole Design

Straight Pole

Recommended Enclosure

105 dm³ (3.7 ft³)

Cone Shape

Exponential

Spider

Double Silicone

Woofer Cone Treatment

TWP Waterproof Both Sides

Recommended Tuning

39 Hz
Technical Specifications

Nominal Diameter

380 mm (15 in)

Minimum Impedance

6.4 Ω

Continuous Power Handling

1400 W

Frequency Range

40 Hz - 2000 Hz

Winding Material

Copper

Winding Depth

21 mm (0.83 in)

Flux Density

1.15 T

Nominal Impedance

8 Ω

Nominal Power Handling

700 W

Sensitivity

97 dB

Voice Coil Diameter

100 mm (4 in)

Former Material

Glass Fibre

Magnetic Gap Depth

9 mm (0.35 in)

Woofer Cone Treatment

TWP Waterproof Both Sides
