Product details

More Information
  • 20 x 24 USB desktop interface
  • Increased ADC headroom with reduced noise and distortion provided by improved THD+N figure
  • Livestreaming made easier with loopback functionality
  • 60dB of gain provided by four Class A microphone preamps
  • Mimicry of tube amp character delivered by two front-mounted JFET instrument inputs
  • Dual ADAT I/O for digital expansion
  • Simultaneous monitoring for two users provided by independent stereo headphone outputs
  • Dedicated talkback, cut, and dim controls for console-style control
  • Low-latency DSP mixer to create up to four stereo art cue mixes
  • Word clock output synchronization for outboard devices
  • Compliant with USB 2.0 and above
  • Road-worthy, all-metal chassis durable enough to face plenty of wear and tear
Technical Specifications
  • Computer Connectivity:USB 2.0
  • Form Factor:Desktop
  • Simultaneous I/O:20 x 24
  • Number of Preamps:4 x mic
  • Phantom Power:Yes
  • A/D Resolution:24bit/96kHz
  • Effects:DSP Mixer, Audio Loop-back
  • Analog Inputs:2 x 1/4" TS (JFET), 4 x XLR-1/4" combo (mic/line)
  • Analog Outputs:4 x 1/4" TRS
  • Digital Inputs:2 x Optical (ADAT/SPDIF)
  • Digital Outputs:2 x Optical (ADAT/SPDIF)
  • Inserts:2 x 1/4" TRS (send), 2 x 1/4" TRS (return)
  • Headphones:2 x 1/4", 1 x 1/8"
  • USB:1 x USB-c
  • Clock I/O:1 x BNC
  • Software:Audient iD Mixer
  • OS Requirements - Mac:macOS 10.13 or later
  • OS Requirements - PC:Windows 10 or later
  • Power Supply:12V DC supply (included)
  • Height:2"
  • Width:10.86"
  • Depth:6.85"
