Product details

More Information
  • Continuity UI combines digital and analog controls for lightning-fast workflow
  • Dual 15.6-inch touchscreens use intuitive gesture control to make things easy
  • Fully assignable layout allows for at-a-glance navigation
  • 24 manual channel strips have 6 switchable banks for easy changes
  • I/O ports can handle 128 x 128 operation at 96kHz for Dante, MADI, Waves, and gigaACE
  • 12 locking XLR inputs with one AES digital input
  • Network I/O and SLink connections easily handle 64 channels at a time
  • 24 assignable SoftKeys let you add extra functionality
  • 12 RackExtra FX slots utilize dedicated returns
  • Onboard word clock function quickly syncs with other digital gear
  • Full metal chassis resists wear and tear
Technical Specifications
  • Type:Digital Mixer
  • Channels:64
  • Inputs - Mic Preamps:12 x XLR (mic/line)
  • Phantom Power:12 Channels
  • Outputs - Main:12 x XLR
  • Inputs - Digital:1 x XLR (AES/EBU)
  • Outputs - Digital:2 x XLR (AES/EBU)
  • Busses/Groups:42 bus architecture ; 16 x DCA Groups, 8 x Mute Groups
  • Data I/O:2 x RJ45 (network), 1 x Locking Ethernet (S-Link)
  • Headphones:1 x 1/8", 1 x 1/4"
  • USB:2 x Type A
  • I/O Expansion Slots:2 x Expansion Card Ports
  • Word Clock:1 x BNC
  • Faders:24
  • A/D Resolution:96kHz
  • Screen:Dual 15.6" touchsreen
  • Power Source:Standard IEC AC cable
  • Height:10.59" (including feet)
  • Depth:24.68"
  • Width:36.1"
  • Weight:57.4 lbs.
  • Manufacturer Part Number:AH-AVANTIS
