Product details

More Information
  • 19″ Rack mountable
  • 16 mic/line inputs with balanced XLR/TRS jack, insert and direct output
  • 100mm faders
  • 4 band EQ with 2 swept mids
  • 6 Aux sends – 2x pre fade / 2x switched / 2x post fade*
  • 2 Stereo returns
  • Dedicated mono output fader – can be switched to provide an L+R mono feed for a centre or fill speaker, or sub bass feed
  • Independent A-B output for 2-track recording, monitor foldback, speaker fills etc
  • Tri-colour, 12 segment bargraph metering
  • Twin FX engines with 20 studio quality FX presets
  • +48V Phantom Power
  • Signal and Peak LEDs
  • Lamp socket
  • Footswitch connector (mutes/unmutes the ST1 FX Return)
Technical Specifications
Tech Specs
  • Type:Analog
  • Channels:16
  • Computer Connectivity:Optional USB expansion card
  • Faders:18 x 100mm
  • Inputs - Mic Preamps:16 x XLR
  • Phantom Power:16
  • Inputs - Line:16 x TRS
  • Outputs - Main:2 x XLR (Main), 1 x XLR (Main Mono)
  • Outputs - Direct:16 x TRS
  • Outputs - Other:2 x TRS (A, B Out)
  • Aux Sends:2 x Pre, 2 x Switched, 2 x Post
  • Send/Return I/O:6 x TRS (Aux Out), 2 x Stereo
  • Channel Inserts:Yes
  • Headphones:1 x 1/4"
  • Talkback:Yes
  • EQ Bands:4-band, 2 x Sweepable Mids
  • Effects:Yes
  • Rackmountable:Yes (removable side trim)
  • Height:7.7"
  • Width:20"
  • Depth:20.9"
  • Weight:35 lbs.
