Product details

More Information
  • Variable pickup patterns: cardioid, omni, figure-8
  • Frequency response: 20Hz-20kHz
  • Max SPL: 155dB
  • Bass roll-off: 300Hz
  • Pad: 20dB
  • Requires +48V phantom power
Technical Specifications

General Specifications

Polar Pattern:

Cardioid, Omnidirectional, and Figure of eight

Audio frequency bandwidth:

20 - 20000 Hz

Equivalent noise level:

15 dB-A

Sensitivity:

28 mV/Pa

Signal to Noise:

79 dB-A

Preattenuation Pad:

-20 dB

Bass cut filter:

300 Hz - 12 dB/octave

Electrical impedance:

<= 200 Ohms

Recommended load impedance:

>= 1000 Ohms

Dimensions

Length:

165 mm

Diameter:

54 mm

Net Weight:

517 g
