MIDAS M32R

MIDAS M32R

The Midas M32R LIVE digital mixing console takes the stellar sound quality and amazing processing power of the M32 and packs it into a portable, rackmountable form factor. You get 16 channel faders and one master fader, the same custom design that gives the M32 its ultra-smooth and precise feel. And with eight DCAs and six mute groups, it's easy to manage larger shows from the compact M32R LIVE. The intuitive layout gives you instant access to your most-needed functions like channel routing, EQ, dynamics, and more. Beyond that, a pre-installed Klark Teknik DN32-LIVE expansion module gives you 32 channels of recording and playback. If you've had your eye on the Midas M32 but really need a more portable solution, call us about the M32R LIVE.

More Information

Midas M32R LIVE Digital Mixing Console Features:

  • Rich, vibrant sound from 16 Midas preamps
  • Incredibly strong yet lightweight, thanks to carbon fiber, aluminum, and steel construction
  • Outstanding signal path with 48kHz digital conversion
  • Impeccable sound quality throughout your signal path, with time-aligned and phase-coherent mix buses
  • Best-in-class motorized faders rated at over 1 million life cycles
  • 32 channels of live recording and playback via a pre-installed Klark Teknik DN32-LIVE expansion module

Technical Specification

Tech Specs

  • Type:Digital Mixer
  • Channels:40
  • Inputs - Mic Preamps:16 x XLR
  • Phantom Power:48V, Switchable per Input
  • Inputs - Line:1 x Dual RCA Stereo (aux)
  • Inputs - Other:6 x 1/4" TRS (aux)
  • Outputs - Main:8 x XLR (main), 2 x 1/4" TRS (monitor)
  • Outputs - Other:6 x 1/4" TRS (aux), 1 x Dual RCA Stereo (aux)
  • Busses/Groups:25 time-aligned/phase-coherent mix buses, 8 DCA groups
  • Talkback:1 x XLR
  • MIDI I/O:In/Out/USB
  • Data I/O:1 x EtherCon (Ultranet), 2 x EtherCon (AES50), 1 x Ethernet
  • Headphones:2 x 1/4" TRS (stereo)
  • USB:1 x Type B, 1 x Type A
  • Computer Connectivity:USB, Ethernet
  • Faders:16 x Input Faders, 1 x Main Fader
  • A/D Resolution:24-bit/48kHz
  • EQ Bands:4-band EQ
  • Effects:8 x Stereo FX Engines
  • Signal Processing:Gate, Compressor
  • Features:100-band RTA, 100 scenes, 100 Snippets, 32-bit/48kHz SD Card recording
  • DAW Control:Yes
  • Screen:5" TFT Display
  • Storage:2 x SD card slots
  • Power Source:Standard IEC AC cable
  • Height:8.2"
  • Depth:24.3"
  • Width:18.8"
  • Weight:31.5 lbs.
