Product details

More Information
  • 18” subwoofer with 4” Voice Coil
  • High power 1000W (PGM) input
  • Cardioid mode capable with processors or DSP onboard power amps
  • Lightweight yet very durable plywood cabinet with premium grade Polyurea coating
  • SpeakON NL4MP x 3 (Parallel x2, Output x1)
  • Dual-pole socket
  • Optional speaker cover (SPCVR-DXS18X) and wheel kit (SPW-1)
  • Durable Black or white finish
Technical Specifications
  • Subwoofer with bass-reflex design
  • Frequency Range (-10 dB):Passive: 32 Hz – 3 kHzNormal: 32 Hz – 150 HzExtend: 29 Hz – 150 Hz
  • LF Driver: 18" cone with 4" voice coil and ferrite magnet
  • Power Handling:Noise: 500 W (EIA 426-A)Program: 1000 W (EIA 426-A)Peak: 2000 W (EIA 426-A)
  • Nominal Impedance: 8 Ω
  • Sensitivity (1 W / 1 m): 100 dB
  • Peak SPL: 133 dB
  • I/O Connectors: SpeakON NL4MP x3 (Parallel x2, Output x1)
  • Handle: Aluminium die-cast, Side x2
  • Pole Socket: Φ35 mm (depth 80 mm), M20 threaded (depth 25 mm)
  • Dimensions (W x H x D): 550 x 657 x 720 mm
  • Net Weight: 43.6 kg (96.1 lbs)
  • Optional Accessories: Cover SPCVR-DXS18X, Caster SPW-1
  • Enclosure Material / Finish / Color: Plywood with durable polyurea coating, Black/White
