Product details

More Information
  • 18" Cone, 4" Voice coil proprietary high-durability speaker unit
  • Plywood cabinet is durable and acoustically optimized for maximum sound quality
  • M20 and Ø35 mm dual pole sockets
  • Optional Speaker Wheels (SPW-1) and Speaker Cover (SPCVR-DXS183)
Technical Specifications
  • Subwoofer with band-pass design
  • Frequency Range (-10 dB):Passive: 35 Hz – 150 HzExtend: 32 Hz – 120 Hz
  • Nominal Impedance: 4 Ω
  • Sensitivity (1 W / 1 m): 96 dB SPL
  • Peak SPL: 129 dB SPL
  • LF Driver: 18" cone with 4" voice coil
  • Power Handling:Noise: 500 WProgram: 1000 WPeak: 2000 W
  • I/O Connectors: speakON NL4MP x2 (Input x1, Output x1)
  • Cabinet Material: Plywood
  • Finish: Durable black polyurea coating
  • Handle: Side x2
  • Pole Socket: Φ35 mm (Depth 80 mm), M20 (Threaded depth 25 mm)
  • Dimensions (W x H x D): 563 x 683 x 721 mm
  • Net Weight: 49.0 kg (108.0 lbs)
  • Optional Accessories: Cover SPCVR-DXS183, Caster SPW-1
