Product details

More Information
  • 12" Cone, 3" Voice coil proprietary high-durability speaker unit
  • Plywood cabinet is durable and acoustically optimized for maximum sound quality
  • M20 and Ø35 mm dual pole sockets
  • Optional Speaker Wheels (SPW-1) and Speaker Cover (SPCVR-DXS123)
Technical Specifications
  • Subwoofer with band-pass design
  • Frequency Range (-10 dB):Passive: 42 Hz – 180 HzExtend: 38 Hz – 140 Hz
  • Nominal Impedance: 4 Ω
  • Sensitivity (1 W / 1 m): 94 dB SPL
  • Peak SPL: 125 dB SPL
  • LF Driver: 12" cone with 3" voice coil
  • Power Handling:Noise: 325 WProgram: 650 WPeak: 1300 W
  • I/O Connectors: speakON NL4MP x2 (Input x1, Output x1)
  • Cabinet Material: Plywood
  • Finish: Durable black polyurea coating
  • Handle: Side x2
  • Pole Socket: Φ35 mm (Depth 80 mm), M20 (Threaded depth 25 mm)
  • Dimensions (W x H x D): 400 x 567 x 570 mm
  • Net Weight: 32.0 kg (70.5 lbs)
  • Optional Accessories: Cover SPCVR-DXS123, Caster SPW-1
