Product details

Technical Specifications

Active or Passive - Active


System Type - Full-Range


Configuration - 2-way


System Continuous Power - 280 W


System Peak Power - 560 W


Max SPL @ 1m - 124 dB


Freq Response (+/-3 dB) - 68 Hz - 20 kHz


Freq Range (-10 dB) - 60 Hz - 20 kHz


Bluetooth - Yes


IP Certification - None


Driver Brand - Wharfedale Pro


LF Driver Size - 8"


LF Voice Coil Size - 2"


LF Rated Impedance - 4 Ω


LF Power (RE:AES2-2012) - 180 W


HF Driver Type - Compression Driver


HF Voice Coil Size - 1.33"


HF Diaphragm Material - Titanium


HF Exit Size - 1.37"


HF Power (RE:AES2-2012) - 30 W


HF Rated Impedance - 8 Ω


Preset Library - No


Input Connector - 2 x 1/4” Jack / XLR Combo


Waveguide Type - Constant Directivity


Enclosure Material - Polypropylene


Grille Material and Finish - Steel Black


Finish - Black Polypropylene


Handles - 1


Deployment - Ground, Flying, Pole, Wall Mount


Pole Mount - Dual Angle (0° / -3°) 35 mm


Brackets Included - No


Rigging - Yes


M8 - 5


Nominal Coverage (H x V) - 90° x 60°


Sensitivity 2.83v / 1m - n/a dB


System Rated Impedance - n/a


Crossover Frequency - 2.0 kHz


Amplifier Design - Class D


DSP Controls - Normal / Live / DJ / Speech


Preset List - Normal / Live / DJ / Speech


Active Loudspeaker Input Impedance - 10 KΩ Balanced


Link Connector - Pin XLR


Input Sensitivity - +4 dBu


Max Input Level - +18 dBu


Line Output - Pin XLR


240 V AC W (1/8 Rated Output Power) - 90


120 V AC W (1/8 Rated Output Power) - 90


Idle W - 20


Main Power - 100-120 V~ / 220-240 V~, 50/60 Hz


Power Supply - SMPS


Unpacked Height (mm) - 460


Unpacked Width Front (mm) - 280


Unpacked Width Rear (mm) - 164


Unpacked Depth (mm) - 269


Packed Height (mm) - 531


Packed Width Front (mm) - 323


Packed Width Rear (mm) - 323


Packed Depth (mm) - 313


Weight Nett (kg) - 10.6


Weight Gross (kg) - 11.9
