The result is a finely tuned system capable of delivering LF: 700 W / MHF: 150 W continuous power (up to LF: 2800 W / MHF: 600 W peak). Built with premium components including copper shorting caps, neodymium magnets, and precision phase plugs, XLA-308 ensures sonic consistency and remarkable detail across the entire frequency range.

Over-engineered for performance, XLA-308 represents the new standard of our line array technology.

Technical Specifications

Technical Specifications

  • System Type: Passive 3-way bi-amp line array element
  • Frequency Response (+/-3 dB): 63 Hz – 20 kHz
  • Frequency Range (-10 dB): 48 Hz – 25 kHz
  • Maximum SPL @ 1m: 140 dB (calculated), 146 dB (peak)
  • Nominal Coverage (H x V):
  • LF Transducer: 2 x 8" neodymium woofers with 2.5" voice coils
  • MHF Transducer: B&C Coaxial compression driver (3" MF coil, 2" HF coil)
  • Power Handling (LF): 700 W Continuous / 1400 W Programme / 2800 W Peak
  • Power Handling (MHF): 150 W Continuous / 300 W Programme / 600 W Peak
  • Impedance: LF:  / MHF:
  • Crossover Frequency: 500 Hz
  • Input Connectors: 2 x speakON NL4
  • Rigging: 3-point integral system,  vertical splay in  steps
  • Enclosure Material: 15 mm / 18 mm Plywood
  • Dimensions: 790 x 269.6/194.2 (front/rear) x 430.7 mm
  • Weight: 33.0 kg (Net) / 72.6 lbs
